Grohe RAPID-SL 2-in-1 Toilet Frame; 6/9 Litre 3 Mode Cistern; 1130mm High Frame; Blue/White

Description

The Rapid SL system gives you the freedom to design your ultimate bathroom by providing a secure and quick method of installing wall-hung basins; bidets; urinals and WCs. Available in three different installation heights; each frame comes pre-assembled with sanitary ware fixings and is subject to stringent testing - our WC frames are tested to hold 400kg.

The Grohe RAPID-SL 2-in-1 Toilet Frame; 6/9 Litre 3 Mode Cistern; 1130mm High Frame; Blue/White is part of the Grohe RAPID-SL 2-in-1 Toilet Frame; 6/9 Litre 3 Mode Cistern; 1130mm High Frame; Blue/White range from Rapid-SL. This Toilet Frame is a basin frame built to last and finished to a very high standard. Consider adding this item to your order today.

• Flushing Cistern Gd 2
• With Small Maintenance Access
• 1.13 M Installation Height
• For On-The-Wall Installations Or Studded Walls
• Powder Coated Steel Frame; Self-Supporting
• For Dry-Cladding; Completely Pre-Assembled
• With Fixed Connections
• For Single Or Series Installation
• Quick Adjustment; Lockable
• Fixing Material; T¼v Approved
• 2 Wc Fixing Bolts; Fixing Device For Ceramic
• Distance Of Fixing Bolts 180/230mm
• Outlet Bend  90mm
• Depth Adjustable
• Reducer  90/110mm
• Inlet And Outlet Connecting Set
• Adjustment Ex Factory 6 L And 3 L
• Pneumatic Discharge Valve Offering 3 Modes Of Operation: Dual Flush Or Start/Stop Or Single Flush
• Water Supply From Left/Right Or Back
• Low Noise (Group I Acc. To
• German Noise Specification)
• Din Approved
• Insulated Against Condensation
• ½" Water Supply Connection Including Integrated
• Angle Valve And Push Fit Flexible Hose Union
• No Tools Required For The Installation
• Of The Inspection Shaft Incl. Protection
• During Construction Phase
• For Vertical Or Horizontal Use
• Accessories For On-The-Wall Installation

Specification
